- CPU (MAX SUPPORT) – i9
- SOCKET – 1200
- CHIPSET – Intel® B560 Chipset
- DDR4 MEMORY – 5066(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4533(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3866(OC) / 3733(OC) /
3600(OC) / 3466(OC) / 3333(OC) / 3200(JEDCE & POR) / 3000(JEDCE & POR) / 2933(JEDCE & POR) / 2800(JEDCE & POR) / 2666(JEDCE & POR) / 2400(JEDCE & POR) / 2133(JEDCE & POR) MHz
- MEMORY CHANNEL – Dual
- DIMM SLOTS – 4
- MAX MEMORY (GB) – 128
- PCI-E X16 – 1
- PCI-E GEN – Gen4
- PCI-E X1 – 2
- SATAIII – 6
- M.2 SLOT – 2
- TPM (HEADER) – 1
- LAN – 1x Realtek® 8125B 2.5Gbps LAN controller
- WIFI & BLUETOOTH – Intel® Wi-Fi 6 AX201, Bluetooth 5.1
- USB 3.2 PORTS (FRONT) – 2(Gen 1, Type A)
- USB 3.2 PORTS (REAR) – 2(Gen 2, Type A), 2(Gen 1, Type A)
- USB 2.0 PORTS (FRONT) – 4
- USB 2.0 PORTS (REAR) – 2
- SERIAL PORTS(FRONT) – 1
- AUDIO PORTS (REAR) – Realtek® ALC897 Codec
- DISPLAYPORT – 1
- VGA – 1
- HDMI – 1
- DIRECTX – 12
- FORM FACTOR – MATX
- OPERATING SYSTEM – Support for Windows® 10 64-bit
